Optimizing Thread Measurement on Coordinate Measuring Machines: Best Practices, Alternatives, and Considerations

Threads pose unique challenges due to their helical nature, requiring careful probe selection, scanning strategies, and evaluation methods to ensure reliable results. This article explores the best methods for measuring internal and external threads on CMMs, fitting algorithms suited to these features, best practices for holes with Geometric Dimensioning and Tolerancing (GD&T) position callouts at Maximum Material Condition (MMC), the viability of Tru-Pos locator gages as alternatives, and the practicality of applying MMC to thread position callouts.
